DC 5V 108kHz Ultrasonic Humidifier Mist Generator Driver Module

₹149.00

In stock ?

In stock

SKU: IFT00069-05 Category: Brand:

DC 5V 108kHz Ultrasonic Humidifier Mist Generator Driver Module is a high-frequency microporous piezoelectric atomization driver board engineered to drive 108 kHz to 113 kHz ultrasonic ceramic mist discs from a regulated 5V DC power source. Powered via a standard 2-pin JST / micro-terminal connection or USB input, this circuit utilizes an ultra-efficient resonant LC tank circuit to step up low-voltage DC into high-frequency alternating drive voltages (approx. 60V–80V peak-to-peak). This electrical oscillation causes connected microporous atomizer discs to vibrate at high frequency, atomizing water droplets through micro-scale apertures into an ultra-fine, cool mist at a rate of 30 to 40 mL/h. With silent operation (≤ 36 dB), low power draw (1.5W–3W), and a compact footprint, it is widely used in commercial humidifiers, aromatherapy diffusers, and DIY misting projects.

Key Features:
  • Tuned 108kHz Resonant Frequency: Specifically calibrated to drive 16 mm and 20 mm microporous ultrasonic atomizing transducer discs at optimal acoustic resonance.
  • Low Power 5V DC Operation: Runs efficiently from a standard 5V power supply, drawing only 1.5W to 3W of power under continuous atomization.
  • Ultra-Quiet Acoustic Performance: Operates at an inaudible sub-36 dB acoustic profile, making it suitable for quiet office and bedside environments.
  • Standard JST 2.0mm Header: Pre-fitted with a JST-SH / PH 2.0 mm 2-pin female socket for quick, solderless connection to replacement mist discs.
  • Timed Auto-Off Protection: Features integrated power timing control that automatically turns off the module after 4 to 8 hours to prevent dry burning.
Technical Specifications:
  • Operating Supply Voltage: 5.0 V DC ± 0.2 V
  • Power Consumption: 1.5 W to 3.0 W
  • Resonant Operating Frequency: 108.0 kHz ± 3.0 kHz
  • Atomization Output Volume: 30 mL/h to 40 mL/h
  • Operating Noise Level: ≤ 36 dB (Acoustically silent)
  • Supported Transducer Types: 16 mm / 20 mm microporous piezoelectric ceramic discs
  • Output Connector: 2-Pin JST PH 2.0 mm pitch female socket
  • Operating Runtime (Auto-Timer): 2 to 8 hours continuous runtime before auto-shutoff
  • Operating Temperature Range: +5°C to +50°C
Mechanical Specifications:
  • Circuit Board Construction: Double-sided FR-4 glass-epoxy PCB with solder mask and silkscreen
  • Switch Type: Miniature onboard momentary tactile switch for power and mode control
  • Mounting: Compact module easily secured with adhesive foam tape or M2 standoffs
  • Net Weight: Approx. 8.0 g
Dimensions:
  • Module Length: 35.0 mm
  • Module Width: 19.0 mm
  • Module Height: 8.0 mm (including inductor coil)
  • Connector Pitch: 2.0 mm
Pinout and Wiring:
  • Power Input (5V / GND): Connect +5.0V DC regulated power to the VCC pad/connector and 0V to the GND terminal.
  • Transducer Socket: Plug the 2-pin lead of your 108 kHz atomizing disc directly into the onboard JST socket.
  • Tactile Button: Single press turns the mist on; second press toggles intermittent mode; third press powers off.
Datasheet Reference:
  • DC 5V 108kHz Ultrasonic Atomizing Spray Driver Circuit Schematic, LC Resonator Tuning, and Piezo Disc Interfacing Guide.
Commonly Used in:
  • Commercial portable mini USB humidifiers and ambient room mist dispensers.
  • Aromatherapy essential oil diffusers and therapeutic cold mist inhalers.
  • Indoor greenhouse seedling cloches and delicate terrarium humidity controllers.
  • Smart home IoT humidification modules controlled via relay or transistor switches.
Applications:
  • Cold Water Atomization: Shearing liquid water into a micro-fine aerosol plume without heating or boiling.
  • Aroma Scent Distribution: Dispersing dilute water-soluble fragrances and essential botanical oils into living spaces.
  • Static Electricity Reduction: Elevating localized relative humidity around sensitive electronic assembly workstations.
  • DIY Maker Gadgets: Building customized smart humidifiers controlled by microcontrollers or environmental sensors.
Equivalent Models:
  • Type-C USB Humidifier DIY Kit: Kit version including pre-soldered Type-C USB jack and mist disc.
  • 113kHz High-Power Mist Driver Board: Slightly higher frequency driver board tailored for high-volume dual-head humidifiers.
  • 24V Industrial Piezo Fogger Board: Heavy-duty submerged mist generator for greenhouse cooling.
Package Includes:
  • 1 × DC 5V 108kHz Ultrasonic Humidifier Mist Generator Driver Module
