u-blox NEO-8M High Precision GPS Module with Electronic Compass for APM 2.6 / 2.8 is a navigation sensor package tailored specifically for ArduPilot APM 2.5, 2.6, and 2.8 open-source drone flight controllers. Integrating a high-sensitivity u-blox NEO-8M GNSS satellite receiver and an external 3-axis I2C electronic compass inside an EMI-shielded circular enclosure, it provides rock-solid position hold and directional stability for multirotor drones and RC aircraft.
Key Features:
- APM 2.6/2.8 Direct Compatibility: Equipped with standard 5-pin GPS and 4-pin I2C connectors matching APM controller headers.
- Onboard 3-Axis Electronic Compass: Relocates magnetic heading detection away from ESC power wiring to eliminate APM “toilet-bowling”.
- High-Gain Multi-Constellation Reception: Receives GPS, GLONASS, and BeiDou satellites simultaneously for robust location lock.
- Aerodynamic Protective Enclosure: Durable circular shell protects the sensitive patch antenna against wind shear, dust, and crash impacts.
- Quick Satellite Acquisition: High-sensitivity LNA front end achieves cold start lock in under 26 seconds.
- Internal Ground Shield: Prevents electromagnetic radiation from video transmitters and motors from desensitizing GPS signals.
Technical Specifications:
- Operating Voltage: 5.0V DC (supplied directly via APM GPS header)
- Operating Current: 50 mA to 75 mA
- GNSS Engine: 72-Channel u-blox M8 core
- Magnetometer IC: HMC5883L / QMC5883L Digital Compass
- Compass Bus: I2C Serial Interface (Address 0x1E / 0x0D)
- GPS Interface: UART TTL (Default 38400 bps / 9600 bps)
- Position Fix Precision: 2.0 meters CEP
- Operating Temperature: -40°C to +85°C
Mechanical Specifications:
- Housing Material: Impact-resistant matte ABS enclosure
- Wiring: Flexible silicone wiring harness with pre-crimped APM Molex connectors
- Cable Length: 20 cm
- Weight: Approximately 30 grams
Dimensions:
- Diameter: 54.0 mm
- Height: 15.0 mm
Pinout and Wiring:
- GPS Connector (5-Pin): VCC (+5V), TX (GPS Out to APM RX), RX (GPS In from APM TX), GND, NC.
- I2C Compass Connector (4-Pin): VCC (+5V), SCL (I2C Clock line to APM I2C port), SDA (I2C Data line), GND.
Datasheet Reference:
- Datasheet Reference: Consult ArduPilot APM 2.6/2.8 External Compass and GPS Setup Documentation and u-blox NEO-8M manual.
Commonly Used in:
- APM 2.6 and APM 2.8 flight controller quadcopters and hexacopters
- Autonomous RC planes, gliders, and flying wings running ArduPlane
- Unmanned survey boats running ArduRover
- Outdoor educational robotics positioning systems
Applications:
- Loiter, Position Hold, and Guided autonomous flight modes
- Automatic Return-to-Launch (RTL) safety trigger
- Multi-waypoint aerial surveillance and photography
- Magnetic heading calibration free of onboard motor interference
Equivalent Models:
- u-blox NEO-7M GPS with Compass for APM
- u-blox NEO-6M GPS with Compass for APM 2.6
- Beitian BN-880 GPS Module
Package Includes:
- 1 × u-blox NEO-8M High Precision GPS Module with Electronic Compass for APM 2.6 / 2.8
