Arduino UNO R3 ATmega328P Development Board with USB Type-C Interface is a modernized revision of the classic 8-bit Arduino UNO R3 microcontroller board, combining the Microchip/Atmel ATmega328P-AU MCU with a reversible USB Type-C port and high-speed CH340C USB-to-UART bridge. Furthermore, it preserves 100% mechanical and pinout compatibility with all standard Arduino UNO R3 shields while upgrading the onboard 5V/3.3V power regulation stage. Consequently, students, educators, and hardware engineers can program and power the board using modern USB-C cables without sacrificing legacy shield and library support.
Key Features:
- Reversible USB Type-C Receptacle: Replaces the bulky legacy USB Type-B socket with a durable, reversible USB-C port for single-cable programming and 5V power delivery.
- Crystal-Less CH340C Serial Bridge: Built-in WCH CH340C USB-to-TTL serial IC features an internal precision oscillator for rock-solid 115200-baud bootloader flashing.
- Genuine ATmega328P 16 MHz Architecture: Provides 32KB Flash memory, 2KB SRAM, 1KB EEPROM, 14 digital I/O pins (6 PWM), and 6 channels of 10-bit ADC.
- 100% Arduino UNO R3 Shield Footprint: Standard 2.54mm female header banks (including dedicated SDA/SCL and IOREF pins) accept all UNO R3 motor, LCD, Ethernet, and sensor shields.
- Dual Power Inputs (USB-C + DC Barrel Jack): Includes an onboard AMS1117-5.0 / NCP1117 linear regulator accepting 7V–12V DC via the 5.5mm × 2.1mm barrel jack.
Technical Specifications:
- Microcontroller: Microchip / Atmel ATmega328P (8-Bit AVR RISC @ 16 MHz)
- USB-to-UART Bridge: WCH CH340C / CH340G High-Speed Serial Controller
- Operating Logic Voltage: 5.0V DC
- Recommended Input Voltage (DC Jack / VIN): 7.0V to 12.0V DC (6V–20V Absolute Limits)
- Digital I/O Pins: 14 Pins (D0–D13; 6 Pins Support 8-Bit Hardware PWM: D3, D5, D6, D9, D10, D11)
- Analog Input Pins: 6 Channels (A0–A5, 10-Bit SAR ADC, 0V–5V Input Range)
- DC Current Capability: 20 mA Recommended per I/O Pin (40 mA Absolute Max) | 150 mA on 3.3V Pin
- Memory: 32 KB Flash (0.5 KB Used by Optiboot Bootloader), 2 KB SRAM, 1 KB EEPROM
Mechanical Specifications:
- PCB Substrate: Standard Arduino UNO R3 Double-Sided FR-4 Fiberglass PCB
- Connectors: USB Type-C Female Port, 5.5mm × 2.1mm Center-Positive DC Barrel Jack, 6-Pin ICSP Header
- Mounting Holes: 4 × 3.2mm (M3) Mounting Holes in Standard UNO R3 Layout
Dimensions:
- Length: 68.6 mm
- Width: 53.4 mm
- Height: 12.5 mm
- Weight: ≈ 24 g
Pinout and Wiring:
- Power Header (`IOREF, RESET, 3.3V, 5V, GND, GND, VIN`): Supply 7V–12V DC to `VIN` or the DC barrel jack, and draw regulated 5V or 3.3V for external sensors.
- UART (D0 RX / D1 TX): Hardware serial port shared with the CH340 USB-C interface.
- I2C (`A4 / SDA` and `A5 / SCL`) & SPI (`D10 SS, D11 MOSI, D12 MISO, D13 SCK`): Dedicated communication buses for displays and SD cards.
- 6-Pin ICSP Header: Direct SPI programming port for USBasp or Arduino-as-ISP bootloader recovery.
- Engineering Precaution: When using a USB-C to USB-C cable from a laptop Thunderbolt/PD port, ensure your cable or board supports 5.1kΩ CC pulldown detection, or use a standard USB-A to USB-C data cable; also disconnect external UART devices from `D0 (RX)` and `D1 (TX)` while uploading sketches.
Datasheet Reference:
Commonly Used in:
- STEM Classroom Coding Kits, Robotics Chassis, and Sensor Prototyping
- CNC Shield V3 Stepper Motor Controllers and 3D Printer Test Rigs
- Home Automation Relay Panels and I2C/SPI Display Dashboards
Applications:
- Rapid Breadboard & Shield Prototyping: Plugs directly into thousands of existing Arduino UNO shields and breadboard jumper harnesses.
- Autonomous Mobile Robotics: Pairs with an L293D or L298P motor driver shield to control 4WD obstacle-avoidance and line-follower robots.
- Automated Lab Instrumentation: Streams 10-bit ADC sensor readings over USB-C virtual COM port to Python, MATLAB, or LabVIEW.
Equivalent Models:
- Arduino UNO R3 DIP (ATmega328P-PU + USB-B): Uses a socketed 28-pin DIP chip and full-size USB-B port, whereas this SMD Type-C version offers a lower profile and modern USB-C connectivity.
- Arduino UNO R3 SMD (ATmega16U2 + USB-B): Includes a programmable ATmega16U2 USB chip for native USB HID emulation.
- LGT8F328P Mini EVB Board: 32MHz enhanced AVR clone with 12-bit ADC and 8-bit DAC.
Package Includes:
- 1 × Arduino UNO R3 ATmega328P Development Board with USB Type-C Interface
