3D Printer & Mini Engraver 3-Axis CNC Shield V3 Expansion Board for Arduino

Price range: ₹62.72 through ₹549.00

In stock ?

SKU: SHIELD-1-11 Category: Brand:

3D Printer & Mini Engraver 3-Axis CNC Shield V3 Expansion Board for Arduino is a 3-axis stepper motor carrier shield engineered for compact desktop CNC laser engravers, PCB milling machines, pen plotters, and DIY 3D printers. Furthermore, it features three 16-pin Pololu-compatible driver sockets (`X, Y, Z`) for A4988, DRV8825, or TMC2208 stepper driver modules alongside an onboard Arduino Nano socket, a 7.5V–12V DC barrel jack, 100µF motor rail filter capacitors, and microstepping selection jumpers. Therefore, it integrates the microcontroller and all three axis drivers onto a single 72mm × 59mm motion-control motherboard compatible with open-source GRBL firmware.

Key Features:
  • Integrated 3-Axis Stepper Driver Sockets (`X, Y, Z`): Hosts up to three A4988 or DRV8825 stepper motor driver carriers to control X, Y, and Z bipolar stepper motors up to 2A per phase.
  • Direct Arduino Nano V3.0 Carrier Socket: Dual 15-pin female headers accept an Arduino Nano V3.0 right on the board, eliminating ribbon cables between the MCU and stepper drivers.
  • Dedicated Limit Switch & I2C/UART Breakout Headers: Provides 3-pinGVS headers for `X-Limit, Y-Limit, Z-Limit` endstops plus 4-pin `I2C` and `UART` headers for offline controllers or Bluetooth modules.
  • Hardware Microstepping Jumper Matrix: 3-pin jumper banks (`M0, M1, M2`) beneath each driver socket configure full-step up to 1/16 (A4988) or 1/32 (DRV8825) microstepping.
  • Dual-Rail Power Distribution: Accepts 7.5V–12V DC via the onboard barrel jack to power both the stepper motor coils and the 5V logic regulator.
Technical Specifications:
  • Supported Axes: 3 Axes (`X, Y, Z`)
  • Compatible Host MCU: Arduino Nano V3.0 (ATmega328P, 30-Pin DIP Layout)
  • Compatible Stepper Drivers: A4988, DRV8825, TMC2208 (16-Pin StepStick Format)
  • Motor Supply Voltage: 7.5V to 12.0V DC via 5.5mm × 2.1mm Barrel Jack (Up to 24V–36V on Motor Rail if Nano `VIN` is Isolated)
  • Stepper Output Connectors: 3 × 4-Pin 2.54mm Male Headers (`2B, 2A, 1A, 1B`)
  • Firmware Compatibility: GRBL v0.9 / v1.1 (With Nano-CNC Pin Mapping in `cpu_map.h`)
Mechanical Specifications:
  • PCB Substrate: Double-Sided Red FR-4 Fiberglass PCB with Dedicated Bulk Electrolytic Capacitors under Each Axis
  • Controls & Jumpers: Onboard Tactile Reset Button, `MOT_V` Power Jumper, and 9 × Microstepping Jumper Positions
  • Mounting Holes: 4 × M3 Corner Mounting Holes
Dimensions:
  • Length: 72.0 mm
  • Width: 59.0 mm
  • Height: 15.0 mm
  • Weight: ≈ 32 g
Pinout and Wiring:
  • Stepper Direction & Step Mapping (CNC V4 Standard): `X_DIR = D5, Y_DIR = D6, Z_DIR = D7` and `X_STEP = D2, Y_STEP = D3, Z_STEP = D4`; Shared `ENABLE = D8`.
  • Endstop Limit Pins: `X_LIMIT = D9, Y_LIMIT = D10, Z_LIMIT = D11`.
  • Driver Insertion Orientation: Align the `EN` (Enable) pin of each A4988/DRV8825 module with the `EN` silkscreen mark on the shield socket.
  • Engineering Precaution: Notice that 3-axis Nano CNC V4 boards swap the `STEP` (`D2–D4`) and `DIR` (`D5–D7`) pins on silkscreen compared to the 4-axis UNO CNC Shield V3 (`STEP = D2–D4` vs `D5–D7`); verify your `cpu_map.h` definitions in GRBL so step pulses go to the `STEP` pins!
Datasheet Reference:
Commonly Used in:
  • Desktop 2-Axis & 3-Axis Diode Laser Engravers and CNC 3018 Routers
  • CoreXY / Cartesian Pen Plotters, EggBots, and PCB Drilling Machines
  • Compact 3-Axis Camera Motion Control Rigs
Applications:
  • GRBL Laser & Milling Control: Runs GRBL 1.1 on a plugged-in Arduino Nano to execute G-code streamed from LaserGRBL, LightBurn, or Universal Gcode Sender (UGS).
  • Automated XY/XYZ Positioning Stages: Drives three NEMA 17 stepper motors with hardware limit-switch homing.
  • Compact Classroom Mechatronics: Provides an affordable 3-axis stepper testbed for teaching G-code kinematics.
Equivalent Models:
  • CNC Shield V3 Expansion Board for Arduino UNO: 4-axis (`X, Y, Z, A`) shield that stacks onto an Arduino UNO R3 instead of hosting an Arduino Nano.
  • 3D Printer CNC Shield V4 for Arduino Nano: Identical 3-axis Nano CNC V4 topology.
  • DRV8825 / A4988 Single-Axis Stepper Shield: Compact 1-axis breakout module when only a single stepper motor is needed.
Package Includes:
  • 1 × 3D Printer & Mini Engraver 3-Axis CNC Shield V3 Expansion Board for Arduino
Weight 50 g
Dimensions 75 × 60 × 15 mm
