AD8232 ECG Sensor With ECG Cable Electrodes

Disposable ECG Electrodes are high-quality, medical-grade sensors designed to capture precise cardiac electrical signals for diagnostic monitoring and stress testing. These electrodes utilize a high-conductivity Ag/AgCl (Silver/Silver Chloride) sensing element to ensure clear traces and minimal baseline wander. Furthermore, the specialized solid gel adhesive provides excellent skin contact while remaining hypoallergenic for patient comfort. Consequently, medical professionals can rely on these sensors for accurate heart rate monitoring and electrocardiogram recordings in various clinical environments. Therefore, these disposable electrodes represent a cost-effective and hygienic solution for hospitals, clinics, and emergency medical services.

Key Features:

• High Conductivity Ag/AgCl Sensor: The silver/silver chloride composition provides superior signal transmission and reduces motion artifacts during monitoring.
• Medical-Grade Adhesive: Features a strong yet gentle adhesive that maintains contact even during patient movement or long-term monitoring sessions.
• Hypoallergenic Material: Utilizes latex-free foam and breathable backing to prevent skin irritation and ensure patient safety.
• Quick Recovery Gel: The integrated conductive gel allows for rapid signal stabilization immediately after placement on the skin.
• Universal Snap Connection: Compatible with standard ECG lead wires and patient cables using a secure metal snap interface.

Technical Specifications:

• Sensor Material: Ag/AgCl (Silver/Silver Chloride)
• Conductive Medium: Solid Conductive Gel
• AC Impedance: ≤ 2.0 kΩ (Standard Testing)
• DC Offset Voltage: ≤ 100 mV
• Combined Offset Instability and Internal Noise: ≤ 150 µV
• Defibrillation Overload Recovery: ≤ 5 mV change within 5 seconds
• Shelf Life: ≈ 24 months (When stored in original sealed pouch)

Mechanical Specifications:

• Backing Material: High-density PE Foam (Polyethylene)
• Connector Type: Stainless Steel Stud (Standard Snap)
• Adhesive Strength: Medical-grade pressure-sensitive adhesive
• Latex Content: 100% Latex-Free

Dimensions:

• Electrode Diameter/Size: ≈ 50 mm x 50 mm (Teardrop or Circular Shape)
• Foam Thickness: ≈ 1.0 mm
• Snap Diameter: ≈ 4.0 mm (Standard size)
• Weight: ≈ 1.5 g per piece

Pinout and Wiring:

• Placement Note: Users must clean and prep the skin surface to remove oils for optimal signal quality.
• Connection Point: Attach the standard ECG lead wire clip or snap onto the metal stud located in the center of the electrode.
• Standard Coding: Follow the AHA (RA, LA, LL, RL, V) or IEC (R, L, F, N, C) color codes on your specific ECG machine for correct anatomical placement.

Datasheet Reference:

• Download 3M Red Dot ECG Electrodes Technical Data Sheet

Commonly Used in:

• Patient Monitoring Systems: Used in bedside monitors for continuous heart rate tracking in ICU and ER settings.
• Diagnostic ECG Machines: Essential for performing standard 12-lead electrocardiograms in outpatient clinics.
• Holter Monitors: Provides reliable long-term adhesion for 24-hour or 48-hour ambulatory monitoring.

Applications:

• Cardiac Stress Testing: Maintains electrical contact even during heavy perspiration and physical exertion on treadmills.
• Emergency Medicine: Allows paramedics to quickly establish cardiac monitoring in the field.
• Surgical Monitoring: Provides intraoperative cardiac surveillance during various medical procedures.
• Sports Science: Tracks heart rate variability and performance metrics in athletic research.

Equivalent Models:

• 3M Red Dot 2560: A widely recognized industry standard for multi-purpose monitoring electrodes.
• Kendall Kitty 100 Series: High-performance cloth or foam electrodes however, these often focus on specific pediatric or adult sizes.
• Ambu BlueSensor: A functional alternative featuring offset connectors to reduce artifacts from lead wire pulling.

Package Includes:

• 1 x Disposable ECG Electrodes
