PIR Motion Detector Sensor Module HC-SR501

60.00
You save

In stock

  • Detection Distance: 3 to 7m (can be adjusted)
  • Wide Working Voltage Range: DC 4.5V- 20V
  • Detection Angle: <140°
  • Work temperature: -20-+80°C
  • Current Drain: <60uA
  • Blockade time: 2.5s (Default)
SKU: SR-08-001 Category: Brand:

Frequently Bought Together

PIR Motion Detector Sensor Module HC-SR501 is a pyroelectric infrared motion sensor that detects human or animal movement within its detection range. With adjustable sensitivity and delay time, it’s widely used in security systems, automatic lighting, and energy-saving applications.

Key Features of HC-SR501 PIR Sensor:
    • High Sensitivity: Detects motion up to 7 meters distance
    • Adjustable Settings: Customizable delay time and sensitivity
    • Dual Output Mode: Repeatable and non-repeatable trigger options
    • Low Power Consumption: Ideal for battery-operated devices
    • Wide Voltage Range: Operates from 4.5V to 20V DC
Technical Specifications of HC-SR501:
    • Operating Voltage: 4.5-20V DC
    • Output Signal: 3.3V TTL (High when motion detected)
    • Detection Range: Up to 7 meters (adjustable)
    • Detection Angle: ≤120°
    • Delay Time: 5-300 seconds (adjustable)
    • Operating Temperature: -15°C to +70°C
    • Dimensions: 32mm × 24mm × 18mm
Mechanical Characteristics of HC-SR501:
    • Lens Type: Fresnel lens array
    • PCB Material: FR-4
    • Weight: Approximately 6 grams
    • Mounting: 2x M2 mounting holes
    • Indicator LEDs: Power and detection status
Wiring Diagram and Connection of HC-SR501:
    • Pin Configuration:
      • VCC: Connect to 5-12V DC power
      • OUT: Digital output signal (3.3V)
      • GND: Connect to power ground
    • Connection Notes:
      • Keep sensor away from heat sources and direct sunlight
      • Adjust sensitivity and delay using onboard potentiometers
      • Warm-up time: 30-60 seconds after power on
Applications of HC-SR501 PIR Sensor:
    • Security Systems: Intrusion detection and alarms
    • Automatic Lighting: Motion-activated lights
    • Energy Saving: HVAC control in occupied spaces
    • Smart Home: Presence detection for automation
    • IoT Devices: Motion-triggered notifications
Equivalent Models of HC-SR501:
    • HC-SR505: Compact alternative with smaller detection range
    • AM312: Low-power miniature PIR sensor
Datasheet:
Keywords for HC-SR501:
    • HC-SR501 PIR Sensor
    • Motion Detection Module
    • Pyroelectric Infrared Sensor
    • Human Detection Sensor
    • Automatic Motion Switch
Package Includes:
    • 1 x HC-SR501 PIR Motion Sensor Module

Additional information

Weight 6 g
Dimensions 32 × 24 × 35 mm
OPERATING VOLTAGE

4.5~20 Volt.

DELAY TIME

5-200S(adjustable)
