IRLML6344TRPBF 30V 5A N-CHANNEL FIELD EFFECT TRANSISTOR SOT-23

The IRLML6344TRPBF is a powerful N-channel MOSFET (Metal-Oxide-Semiconductor Field-Effect Transistor) designed for efficient switching and amplification of electrical signals in various electronic circuits. With a low gate threshold voltage and high current handling capacity, this transistor is well-suited for applications requiring high-speed switching and robust performance. The compact SOT-23 package enhances its versatility, making it suitable for use in power management, motor control, and battery protection systems.

Key Features of IRLML6344TRPBF 30V 5A Field Effect Transistor:

• • Low RDS(on): Provides low on-state resistance for minimal conduction losses.
  • High Current Rating: Handles up to 5A of continuous drain current.
  • Low Gate Threshold Voltage (VGS(th)): Enables efficient switching with low control voltage.
  • Fast Switching Speed: Facilitates rapid switching transitions for high-frequency applications.
  • SOT-23 Package: Compact surface-mount package for space-constrained applications.

Technical Specifications of IRLML6344TRPBF 30V 5A Field Effect Transistor:

• • Maximum Drain-Source Voltage (VDS): 30V.
  • Continuous Drain Current (ID): 5A.
  • Maximum Power Dissipation (PD): 1.25W.
  • Gate-Source Voltage (VGS): ±20V.
  • On-State Resistance (RDS(on)): 0.04Ω (typical) at VGS = 4.5V.
  • Operating Temperature Range: -55°C to +150°C.

Mechanical Specifications of IRLML6344TRPBF 30V 5A Field Effect Transistor:

• • Package Type: SOT-23 (3-pin surface-mount).
  • Dimensions: Small footprint suitable for compact circuit designs.
  • Weight: Lightweight and easy to handle during assembly.

Dimensions:

• • Length: Approximately 2.9mm
  • Width: Approximately 1.3mm
  • Height: Approximately 1.0mm
  • Weight: Very lightweight for minimal impact on PCBs.

Mounting Options:

• • Surface Mount: Designed for direct placement on PCBs using reflow soldering.
  • Heat Dissipation: Efficient thermal management required for high-current applications.

Schematic Diagram, Connection, Wiring and Pinout of IRLML6344TRPBF 30V 5A Field Effect Transistor:

• • Pin Configuration: Includes gate (G), drain (D), and source (S) pins.
  • Connection: Connect drain and source to the load circuit, and gate to the control signal.
  • Wiring: Ensure proper orientation and secure soldering for reliable operation.

Datasheet of IRLML6344TRPBF 30V 5A Field Effect Transistor:

• • Datasheet

Applications of IRLML6344TRPBF 30V 5A Field Effect Transistor:

• • Power Management Systems: Switching regulators and DC-DC converters.
  • Motor Control: Drive circuits for DC motors and servos.
  • Battery Protection: Current limiting and protection circuits.
  • LED Lighting: LED drivers and lighting control systems.
  • Consumer Electronics: High-speed switching applications in smartphones and tablets.

Equivalent of IRLML6344TRPBF 30V 5A Field Effect Transistor:

• • IRLML6344PbF: Similar specifications with lead-free packaging.
  • AO3401: Comparable N-channel MOSFET with different package options.

Keywords for IRLML6344TRPBF 30V 5A Field Effect Transistor:

• • IRLML6344TRPBF U2HFS UKDFA MOSFET
  • 30V N-Channel Transistor
  • 5A Power MOSFET
  • SOT-23 MOSFET
  • High Current MOSFET

Package Includes:

• • 1 x IRLML6344TRPBF 30V 5A Field Effect Transistor
