XH2.54 10P Male Connector Header 2.54mm – White

Selction Available:

• • JST XH2.54 10 Pin 2.54mm Pitch Plastic Shell Male Plug
  • JST XH2.54 10 Pin 2.54mm Pitch Plastic Shell Female Plug
  • JST XH2.54 10 Pin 2.54mm Pitch Plastic Shell

Technical Specifications:

• • JST-PH family
  • 2.54mm pin pitch
  • Rated 2A AC, DC(AWG #24), 100V AC, DC
  • Initial contact resistance of 10mΩ max.
  • Insulation resistance: 1000 MΩ min
  • Withstanding voltage: 800V AC/minute
  • Applicable wire: AWG #32 to #24

Applications:

• • Rechargeable battery packs
  • Radio-controlled servos
  • Battery balancers, etc.

Known As:

• • JST-XH Connectors
  • 10 Pin Male Connector

Package Includes:

• • 1 X 10 Pin JST-XH male Housing 2515 Connector – 2.54mm Pitch
