VS1838B TSOP INFRARED RECEIVER MODULE

7.00
You save

In stock

SKU: BR1-IFT-004-09 Category:

The VS1838B is a miniature, high-performance infrared receiver module designed to receive signals from infrared remote controls. It is widely used in various applications such as consumer electronics, home automation, and remote control systems. The module is highly sensitive, ensuring reliable operation even in low-light environments.

Key Features of VS1838B Infrared Receiver Module:
    • High Sensitivity: Capable of detecting weak infrared signals from remote controls over long distances.
    • Compact Design: Small and lightweight, making it suitable for use in space-constrained projects.
    • Low Power Consumption: Efficient design that minimizes power consumption, making it ideal for battery-powered applications.
    • Wide Range of Applications: Compatible with a variety of infrared remote controls for home electronics, lighting, and other devices.
    • Built-in Demodulation: Integrated demodulation circuitry simplifies interfacing with microcontrollers.
Technical Specifications of VS1838B Infrared Receiver Module:
    • Model: VS1838B
    • Operating Voltage: 2.7V to 5.5V
    • Operating Frequency: 38kHz
    • Reception Distance: 18-20 meters (max)
    • Carrier Frequency: 38kHz
    • Package Type: Epoxy resin package
Mechanical Specifications of VS1838B Infrared Receiver Module:
    • Module Type: Through-hole IR receiver module
    • Dimensions: Compact size, suitable for small electronics projects
Schematic Diagram, Connection, Wiring, and Pinout of VS1838B Infrared Receiver Module:
    • Pin Configuration:
    • 1: GND – Ground
    • 2: VOUT – Output pin for received infrared signals
    • 3: VCC – Power supply input (2.7V-5.5V)
DataSheet:
Applications of VS1838B Infrared Receiver Module:
    • Remote Control Systems: Used in IR-based remote controls for TVs, air conditioners, and other appliances.
    • Home Automation: Integrated into home automation systems for controlling lights, fans, and other devices using remote controls.
    • Consumer Electronics: Widely used in DVD players, set-top boxes, and other consumer electronics requiring infrared reception.
    • DIY Projects: Ideal for hobbyist projects involving infrared signal reception and microcontroller interfacing.
    • Arduino Projects: Commonly used with Arduino for remote control projects and IR-based communication.
Equivalent of VS1838B Infrared Receiver Module:
    • TSOP1738: A similar IR receiver with comparable functionality and pin configuration.
    • HS0038B: Another equivalent IR receiver module with 38kHz carrier frequency.
Keywords for VS1838B Infrared Receiver Module:
    • Infrared Receiver
    • IR Remote Control
    • VS1838B IR Module
    • 38kHz IR Receiver
    • IR Sensor Module
Package Includes:
    • 1 x VS1838B TSOP Infrared Receiver Module
