PICKIT3 Debugger Programmer

PICKIT3 Debugger Programmer is a versatile tool for programming and debugging Microchip PIC microcontrollers and dsPIC Digital Signal Controllers. It offers in-circuit debugging, making it essential for embedded systems development and troubleshooting.

Key Features of PICKIT3 Debugger Programmer:

• • In-Circuit Debugging: Supports real-time debugging for precise analysis.
  • Wide Compatibility: Compatible with a wide range of Microchip PIC and dsPIC devices.
  • USB Interface: High-speed USB communication for easy integration.
  • Compact Design: Lightweight and portable for convenient use.
  • Firmware Upgradeable: Stay up-to-date with Microchip’s latest device support.

Technical Specifications of PICKIT3 Debugger Programmer:

• • Supported Devices: PIC10, PIC12, PIC16, PIC18, PIC24, dsPIC, and more
  • Power Supply: 5V via USB
  • Connection Interface: USB 2.0
  • Debugging Features: Breakpoints, watch variables, single-step execution
  • Programming Voltage: 2.0V to 5.5V
  • Operating System Support: Windows, Linux, macOS
  • Dimensions: 90mm x 45mm x 15mm

Schematic Diagram and Pinout of PICKIT3 Debugger Programmer:

• • Pinout:
    • Pin 1 (MCLR): Master clear/reset.
    • Pin 2 (VDD): Target device power supply.
    • Pin 3 (GND): Ground connection.
    • Pin 4 (PGD): Data line for debugging/programming.
    • Pin 5 (PGC): Clock line for debugging/programming.
    • Pin 6 (AUX): Auxiliary connection (optional).
  • Schematic Diagram: The PICKIT3 consists of a USB interface, voltage regulator, and control logic for debugging/programming operations.

Applications of PICKIT3 Debugger Programmer:

• • Embedded System Development: Program and debug PIC microcontrollers.
  • Educational Purposes: Ideal for learning microcontroller programming.
  • Prototyping: Test and validate designs before production.
  • Troubleshooting: Debug firmware issues in existing systems.

Equivalent Models of PICKIT3 Debugger Programmer:

• • PICKIT4: Advanced model with faster debugging and programming capabilities.
  • ICD3: High-performance debugger and programmer from Microchip.

Datasheet:

• • Download PICKIT3 Datasheet

Keywords for PICKIT3 Debugger Programmer:

• • PICKIT3
  • PIC Debugger Programmer
  • Microchip PICKIT
  • In-Circuit Debugger
  • PIC Programmer

Package Includes:

• • 1 x PICKIT3 Debugger Programmer
  • 1 x USB Cable
  • 1 x Debugging Cable
