5mm LDR Sensor Photoresistor (GL5516) is a light-sensitive resistor that changes its resistance based on the intensity of light falling on it. It is widely used in light detection and control circuits.
This is a small LDR which can be used for making a light sensor, color sensor, object sensor, line sensor, etc .
Model | Light resistance (10 Lux) KOhm |
Dark resistance MOhm |
GL5506 | 2-6 | 0.15 |
GL5516 | 5-10 | 0.5 |
GL5528 | 10-20 | 1 |
GL5537 | 16-50 | 2 |
GL5539 | 30-90 | 5 |
Key Features of GL5516 LDR:
-
- Photoresistor: Resistance decreases as light intensity increases.
- Compact Size: 5mm head diameter, suitable for small spaces.
- Cost Effective: Ideal for mass applications and educational projects.
- Passive Component: Requires no power supply to function.
Technical Specifications:
-
- Model: GL5516
- Head Diameter: 5mm
- Dark Resistance: ≥ 1MΩ
- Light Resistance: 5KΩ to 10KΩ (at 10 Lux)
- Max Voltage: 150V DC
- Power Consumption: < 100mW
- Spectral Peak: 540 nm
Wiring Diagram:
-
- Connect one end to VCC through a pull-up resistor (e.g., 10KΩ)
- Connect the other end to GND
- Measure voltage across the LDR using an analog input pin (A0)
Applications:
-
- Automatic Light Control
- Solar Garden Lights
- Brightness Adjustment in LCD Displays
- Light-Sensitive Alarms
- Light Detection in Robotics
Equivalent Models:
Datasheet / Resources:
Keywords:
-
- GL5516 Photoresistor
- 5mm LDR Sensor
- Light Dependent Resistor
- Ambient Light Sensor
- Analog Light Detector
Package Includes:
-
- 1 x GL5516 5mm LDR Photoresistor
Additional information
Weight | 0.235 g |
---|---|
mm | 5mm |
HSN Code | 85340000 |
