KSD9700 250V 5A Metal Thermostatic Temperature Switch NC 85° C

25.00
You save

In stock

KSD9700 250V 5A Metal Thermostatic Temperature Switch NC 85° C is a compact and reliable bimetal temperature controller that opens the circuit when the ambient temperature reaches 85°C. It is widely used for overheating protection in electrical equipment and appliances.

Key Features of KSD9700 85°C NC Thermostat:
    • Rated Operating Temperature: Opens at 85°C to prevent overheating.
    • Normally Closed (NC): Circuit remains closed under normal temperature conditions and opens at the preset limit.
    • Compact Design: Small, sealed metal body with insulated leads for easy integration.
    • Reliable Bimetal Disc: Precise temperature response and reset without external power.
    • Automatic Reset: Closes again when the temperature drops below the cutoff limit.
Technical Specifications of KSD9700 250V 5A NC Thermostat:
    • Model: KSD9700
    • Type: Normally Closed (NC)
    • Rated Temperature: 85°C ± 5°C
    • Rated Voltage: 250V AC
    • Rated Current: 5A
    • Contact Resistance: ≤ 50 mΩ
    • Insulation Resistance: ≥ 100 MΩ
    • Temperature Tolerance: ±5°C
    • Leads: Pre-soldered wires approx. 70mm length
Mechanical Characteristics of KSD9700 Thermostat:
    • Housing: Metal Casing (sealed)
    • Dimensions: Approx. 20mm x 7mm x 3.5mm
    • Lead Length: Approx. 70mm
    • Mounting: No screw hole (place via adhesive or clamping)
    • Weight: Approx. 3g
Wiring Diagram and Pinout for KSD9700 NC Switch:
    • Red Wire: Live input/output (interchangeable)
    • Black Wire: Neutral input/output (interchangeable)
    • Normally Closed Operation: Conducts current under normal temperature; opens when 85°C is reached.
Applications of KSD9700 85°C Thermostatic Switch:
    • Motor Overheat Protection: Embedded in motor windings for thermal cutoff.
    • Battery Packs: Protects Li-ion/NiMH batteries from overheating during charge/discharge.
    • Heaters and Boilers: Cuts off circuit when temperature exceeds safe limits.
    • Power Supplies: Ensures safe operating temperatures for transformers and adapters.
    • LED Drivers and Inverters: Thermal protection in compact electronics systems.
Equivalent Models:
Datasheet:
Keywords for KSD9700 85°C NC Temperature Switch:
    • KSD9700 Thermostat
    • 85°C Thermal Cutoff Switch
    • NC Temperature Control Switch
    • Thermal Protector 250V 5A
    • Bimetal Temperature Controller
Package Includes:
    • 1x KSD9700 250V 5A Metal Thermostatic Temperature Switch NC 85°C

Additional information

Weight 3 g
Be the first to review “KSD9700 250V 5A Metal Thermostatic Temperature Switch NC 85° C”

Reviews

There are no reviews yet.
