GY-511 LSM303DLHC 3-AXIS E-COMPASS SENSOR

GY-511 module includes a 3-axis accelerometer and a 3-axis magnetometer. This sensor can measure the linear acceleration at full scales of ± 2 g / ± 4 g / ± 8 g / ± 16 g and magnetic fields at full scales of ± 1.3 / ± 1.9 / ± 2.5 / ± 4.0 / ± 4.7 / ± 5.6 / ± 8.1 Gauss. When you place this module in a magnetic field, according to the Lorentz law, a current is induced in its microscopic coil. The compass module converts this current to the differential voltage for each coordinate direction by calculating these voltages, you can calculate the magnetic field in each direction and obtain the geographic position. It communicates using I2C communication protocol and the voltage level required to power this device is 3V-5V. You can use it in DIY GPS system, accelerometer data acquisition system to be used in Vehicles etc.

Features:

• • Chip built-in 16bit AD converter, 16-bit data output.
  • I2C Digital-output of 6 or 9-axis MotionFusion data in rotation matrix, quaternion, Euler Angle, or raw data format.
  • Selectable Solder Jumpers on CLK, FSYNC, and AD0.
  • Digital Motion Processing (DMP) engine offloads complex MotionFusion, sensor timing synchronization, and gesture detection.
  • Embedded algorithms for run-time bias and compass calibration. No user intervention required.
  • Digital-output temperature sensor.

Package Includes:

• • 1 X GY-511 LSM303DLHC high-precision 3 Axis electronic compass acceleration sensor module
