CJMCU-9900 APDS9900 DIGITAL AMBIENT LIGHT PROXIMITY SENSOR MODULE

This is CJMCU 9900 APDS-9900 Digital Proximity And Ambient Light Sensor For Arduino. The APDS-9900 provides digital ambient light sensing (ALS), IR LED, and a complete proximity detection system in a single 8 pin package. The proximity function offers plug and plays detection to 100 mm (without front glass) thus eliminating the need for factory calibration of the end equipment or sub-assembly.

The proximity detection feature operates well from bright sunlight to dark rooms. The wide dynamic range also allows for operation in short distance detection behind dark glass such as a cell phone.

In addition, an internal state machine provides the ability to put the device into a low power mode in between ALS and proximity measurements providing very low average power consumption. The ALS provides a photopic response to light intensity in very low light conditions or behind a dark faceplate.

• • Optical modules integrated with ALS, infrared LEDs, and proximity detectors
  • Ambient Light Sensing (ALS)
  • Approximate human visual response
  • Programmable interrupt capability with upper and lower thresholds
  • Up to 16-bit resolution
  • High sensitivity operation behind dark glass
  • 0.01lux low lumen performance
  • Proximity detection
  • Fully calibrated to 100 mm detection
  • Integrated infrared LED and synchronous LED driver
  • Eliminates factory calibration of the proximity sensor
  • Programmable wait timer
  • Wait for state power consumption – 90μA typical
  • Programmable range from 2.7 ms to more than 8 seconds
  • I2C interface compatible
  • Up to 400kHz (I2C fast mode)
  • Dedicated interrupt pin.

Applications:

• • Adjustable light mobile phone backlight
  • Notebook / display security
  • automatically enabled hands-free mode
  • An automatic menu pops up
  • Digital camera eye sensor.

Package Includes:

• • 1 X CJMCU 9900 APDS-9900 Digital Proximity And Ambient Light Sensor.
