400 Tie Points Contacts Mini Circuit Experiment Solderless Breadboard

400 Tie Points Contacts Mini Circuit Experiment Solderless Breadboard offers electronics enthusiasts and students a compact, efficient platform for rapidly prototyping circuits without the mess and permanence of soldering. This miniature breadboard includes 400 convenient tie points, providing ample capacity for small to medium-sized projects, including basic microcontroller setups. Consequently, you can quickly insert and remove components like ICs, resistors, and capacitors to test and iterate your designs immediately. Its small footprint and self-adhesive backing make it ideal for portable projects, quick diagnostics, or integrating into larger circuit boards for dedicated sections. Therefore, grab this essential tool to simplify your design process and accelerate your learning in electronics.

Key Features:

• Solderless Design: Allows for quick and easy insertion and removal of components and wires, which greatly speeds up prototyping and troubleshooting.
• 400 Tie Points: Provides a substantial number of connection points, which is sufficient for small microcontroller projects, sensor interfaces, and basic logic circuits.
• Interlocking Capability: You can laterally connect multiple 400-point breadboards together to form larger prototyping areas, significantly increasing flexibility.
• Integrated Power Rails: Includes two dedicated power rails (one VCC and one GND) on each side, simplifying power distribution across your circuit.
• Self-Adhesive Backing: A peel-and-stick backing allows you to firmly mount the breadboard onto project enclosures or base plates.

Technical Specifications:

• Total Tie Points: 400 (300 in the component area and 100 in the power rails)
• Contact Life: ≥ 10,000 insertions per point
• Wire Size Accommodation: 20 to 29 AWG (0.3 to 0.8 mm diameter)
• Rated Voltage/Current: 300 V / 3 A max (Non-continuous)
• Insulation Resistance: ≥ 100 MΩ at 500 V_DC
• Operating Temperature Range: −20°C to +80°C

Mechanical Specifications:

• Body Material: ABS Plastic (High-impact, durable material)
• Internal Contacts: Phosphor Bronze or Nickel-plated Brass Spring Clips
• Grid Pitch: Standard 2.54 mm (0.1 inch)
• Polarity Markings: Clearly labeled positive (+) and negative (−) strips for power rails.

Dimensions:

• Length: ≈ 82 mm
• Width: ≈ 55 mm
• Height: ≈ 8.5 mm (Including adhesive backing)
• Weight: ≈ 40 g (Extremely lightweight for portability)

Pinout and Wiring:

• Component Area: Connects pins vertically (along the blue lines); five holes in each row connect internally.
• Power Rails: Connects pins horizontally (along the red lines); all holes in a rail connect internally, running the full length of the board.
• Center Channel: The central insulating channel separates the two vertical sections, accommodating DIP ICs (Dual In-line Packages).
• Wiring Note: Always use solid-core jumper wires for the most reliable connections; avoid stranding wires on breadboards.

Datasheet Reference:

• Download 400 Tie Points Breadboard Reference Data

Commonly Used in:

• Educational Kits: Students commonly use these boards to learn basic circuit theory and practical electronics.
• Microcontroller Development: The size perfectly suits projects using Arduino UNO, ESP32, or PIC development boards.
• Hobbyist Projects: Perfect for testing small sensor circuits, LED drivers, and simple logic gates.

Applications:

• Rapid Prototyping: You can quickly assemble and disassemble temporary electronic circuits for proof-of-concept testing.
• Circuit Debugging: Electrical engineers leverage its easy access to component terminals for real-time signal probing and fault isolation.
• Portable Demos: Furthermore, its compact size makes it an excellent choice for building small, handheld demonstration circuits.

Equivalent Models:

• BB400: The standardized nomenclature for 400-tie point mini breadboards.
• SYB-46: A common model designation that shares the same layout and dimensions.
• Half-Size Breadboard: Often referred to by this descriptive name in electronic supply catalogs.

Package Includes:

• 1 x 400 Tie Points Mini Circuit Experiment Solderless Breadboard
