0.2W ORANGE SMD LED-4014

This is a 0.2 Watt ORANGE high-quality SMD LED. These LED’s consume very low power and emit much intense bright light, many times more than a normal LED, and generally produce a wide angle of light disbursement which can be narrowed through the use of an external lenses.

SMD LEDs are substantially smaller than lead frame type components, they can be used on smaller boards, with higher packing density, less storage area, and smaller equipment. Just like the other LED’s SMD LED has two pins, anode and cathode for powering the LED.

Suggetion to use resistor based on brightness requirmets.

• • Package ( L/W/H ) : 4 × 1.4× 0.7 mm
  • Lens: Water Clear Flat Mold
  • EIA STD Package
  • Meet ROHS, Green Product
  • Compatible With SMT Automatic Equipment
  • Compatible With Infrared Reflow Solder And Wave Solder Process

Electrical Characteristics:

• • Power Dissipation – mW
  • Peak Forward Current – mA
  • DC Forward Current -mA
  • Reverse Voltage – 5V
  • Color Temperature – K
  • Luminous Intensity – mcd
  • Viewing Angle(deg) – nm
  • Forward Voltage – V
  • Reverse Current – 5uA

Tolerances:

• • Luminous Intensity: ± 15%
  • HUE: ±1nm
  • Forward Voltage: ± 0.1V
